ARMO 3D cross line laser with 2 vertical lines

ADA ARMO 3D Three-Line Laser (Heavy Duty)

This ADA ARMO 3D is a 3-line laser with 2 vertical lines specially designed for the toughest conditions. This line laser is for heavy-duty use and can take a beating. Ideal for building sites.

Professional
This line laser is very professional. Thanks to the high quality interior and exterior, this line laser can take a beating. This makes the line laser ideal for rough construction sites.

Handy
The line laser can be set in various positions. On the line laser, the three laser lines can be switched on and off separately. The line laser can also be set in manual mode. In this, the line laser can be set at an angle.

Safe
When the ADA line laser is outside its 4-degree levelling range, the laser lines start flashing, preventing unexpected measurement errors. A slider on the side of the device allows the line laser to be conveniently placed on the transport lock. This way, the pendulum system will not be damaged during transport.

Specifications:

Accuracy: 2 mm / 10 metres
Range: 30 metres*
Range with receiver: 70 metres
Laser lines: 1x horizontal, 1x vertical
Lines separately switch on/off: Yes
Afschot: Manual
Laser diode: Class 2, 635 nm
Levelling range: 4 degrees
Protection: IP64
Working time per battery/batteries: 18 hours*
Power supply: 3x AA battery
Working temperature: 0°C to 40°C
Weight: 400 gr
Connection: 1/4"
Dimensions LxWxH: 100 x 100 x 165 mm

*in the most favourable conditions

Scope of delivery:

- ADA Armo 2D
- Carrying case
- Magnetic wall bracket
- Tripod adapter
- Battery pack
